JM1800PLUS液压破碎锤
|
|
|
JM1800PLUS液压破碎锤
|
矫马1800加强型液压破碎锤技术源自韩国TPD-TORPEDO，该款机器具有对挖掘机要求低，打击力打，爆发力强劲，售后成本低，性能稳定等多种特性
| Model | JM1800PLUS | JM1850PLUS | JM1900PLUS | TP700 | TP700 | |
| Description | unit | |||||
| Body Weight | kg | 2716 | 2986 | 3695 | 3695 | 3695 |
| lb | 5423 | 6569 | 8146 | |||
| Operating Weight | kg | 3909 | 3950 | 6300 | ||
| lb | 8618 | 8,690 | 13889 | |||
| Setting pressure | bar | 250 | 250 | 250 | ||
| psi | 3626 | 3626 | 3626 | |||
| Required Oil Flow | ℓ/min | 280~350 | 280~350 | 360~450 | ||
| gal/min | 74.6~93.1 | 74.6~93.1 | 96~120 | |||
| Operating pressure | bar | 190~210 | 190~210 | 190~210 | ||
| psi | 2755~3045 | 2755~3045 | 2755~3045 | |||
| Impact Rate | bpm | 230~320 | 230~320 | 230~320 | ||
| Hose Diameter | inch | 1.1/4" | 1.1/4" | 1¼",1½" | ||
| Rod Diameter | mm | 180 | 185 | 190 | ||
| in | 7.1 | 7 | 8.3 | |||
| Applicable Carrier | ton | 50~60 | 50~60 | 60~90 | ||
| Back head sealed gas pressure | bar | 23~25 | 23~25 | 23~25 | ||
| psi | 336~363 | 336~363 | 336~363 | |||
此表格提供者为韩国TPD株式会社，详情请咨询我公司工程师 400-890-1982
